| Digital Output |
Channels |
16 |
| Load Voltage |
5 VDC ~ 30 VDC |
|
| Load Current |
100 mA/Channel |
|
| Isolation Voltage |
3750 VDC |
|
| Digital Input |
Channels |
16 |
| Input Voltage |
0 VDC ~ 30 VDC |
|
| ON State |
3.5 VDC(mininum) |
|
| OFF State |
2 VDC(maxinum) |
|
| Input Impedance |
3 kOhm |
|
| Isolation Voltage |
3750 VDC |
|
| LED
Display |
1 LED as
Power indicator 16 LEDs as Digital Output indicators 16 LEDs as Digital Input indicators |
|
| Power
Consumption |
Maxinum
1.25 W |
|
|
I-87042W
Wire Connection
|
|
 |
 |
| Configuration | Default Setting | Description |
|---|---|---|
| Type | 40 | Digital Input/Output |
| Baudrate | 0A | 115200 bps |
| Format | 00 | CheckSum disable |
