| Analog
Input |
Input Channels |
8 differential/16 single-ended
|
| Input Type |
+/- 10V, +/- 5V, +/- 1V
+/- 500mV, +/- 150mV
-20mA ~ +20mA
(with external 125 Ohms resistor) |
| Resolution |
16-bit / 12-bit |
| Sampling Rate |
Normal Mode : 16-bit,10 Samples/Sec(Total) |
| Fast Mode : 12-bit, 60 Sample/Sec(Total) |
| Accuracy |
Normal mode : 0.1% of FSR |
| Fast mode : 0.5% of FSR |
| -3dB BandWidth |
15.7Hz |
| Zero drift |
+/- 20 μV/ °C |
| Span drift |
+/- 25 ppm/ °C |
| Common Mode Rejection |
86dB |
| Normal Mode Rejection |
100 dB |
| Input Impedance |
Differential: 2M Ohms, Single-Ended: 1M Ohms
|
| Overvoltage Protection |
Differential: 240Vrms, Single-ended: 120Vrms
|
| Individual Channel Configuration |
Yes |
| Intra-module Isolation, Field to
Logic |
3000VDC |
| LED Display |
1 LED as Power/Communication indicator
|
| Power Consumption |
Maximum : 1.1W |
